Techninės specifikacijos
Basic Information
Form Factor
20 x 20 mm
Application
Multi-rotor Aircraft
Width
27.0 mm
Height
5.0 mm
Depth
27.0 mm
Weight
3.3 g
Protective case is included
No
Retail Price
US$ 35.00
Release date
Jul 2017
Brand
Hobbywing
Integrated Circuits
CPU Family
F4
CPU Model
STM32F405
Main MPU
MPU6000
Auxiliar MPU
No
Barometer
No
Compass
No
Inputs and Outputs
PWM Outputs
4
Number of UARTs (total)
3
Inverted UARTs
1
SoftSerial Inputs
0
I2C input
No
Buzzer output
Yes
LED Strip Output
Yes
Current Sensor Analog Input
Yes
RSSI Analog Input
No
VBAT Input
Yes - Up to 4S (17V)
Shared UART with USB
No
Racing Transponder Led Output
No
Features
Has 5V voltage regulator
Yes - 1A
Soft mounted gyro
No
Soft mounted corners
No
Has OSD
Yes - Native
Onboard current sensor
No
Has SD Card Slot
No
Has PDB
No
Has VTX
No
Has 4 in 1 ESCs
No
Resources
BetaFlight Target
OMNIBUSF4SD
