Techninės specifikacijos
Basic Information
Form Factor
30,5 x 30,5 mm
Application
Multi-rotor Aircraft
Width
36.0 mm
Height
8.0 mm
Depth
40.0 mm
Weight
22.0 g
Protective case is included
No
Retail Price
US$ 67.00
Release date
Dec 2017
Brand
Racerstar
Integrated Circuits
CPU Family
F4
CPU Model
STM32F405
Main MPU
MPU6000
Auxiliar MPU
No
Barometer
No
Compass
No
Inputs and Outputs
PWM Outputs
0
Number of UARTs (total)
2
Inverted UARTs
1
SoftSerial Inputs
0
I2C input
No
Buzzer output
Yes
LED Strip Output
Yes
RSSI Analog Input
No
VBAT Input
Yes - Up to 4S (17V)
Shared UART with USB
No
Racing Transponder Led Output
No
Features
Has 5V voltage regulator
Yes - 1A
Soft mounted gyro
No
Soft mounted corners
No
Has OSD
Yes - Native
Onboard current sensor
Yes - Up to 120A
Has SD Card Slot
No
Internal Memory for Blackbox
0MB
Has PDB
No
Has VTX
No
Has 4 in 1 ESCs
Yes - 4x30A BLHeli_S BB2
Resources
BetaFlight Target
OMNIBUSF4
InavFlight Target
OMNIBUSF4
