Techninės specifikacijos
Basic Information
Form Factor
30,5 x 30,5 mm
Application
General use
Width
36.0 mm
Height
5.0 mm
Depth
36.0 mm
Weight
6.0 g
Protective case is included
No
Retail Price
US$ 35.00
Release date
Apr 2016
Brand
Seriously Pro
Integrated Circuits
CPU Family
F3
CPU Model
STM32F303
Main MPU
MPU9250
Auxiliar MPU
No
Barometer
BMP280
Compass
MPU9250
Inputs and Outputs
PWM Outputs
8
Number of UARTs (total)
3
Inverted UARTs
3
SoftSerial Inputs
2
I2C input
Yes
Buzzer output
Yes
LED Strip Output
Yes
Current Sensor Analog Input
Yes
RSSI Analog Input
Yes
VBAT Input
Yes - Up to 4S (17V)
Shared UART with USB
No
Racing Transponder Led Output
Yes
Features
Has 5V voltage regulator
No
Soft mounted gyro
No
Soft mounted corners
No
Has OSD
No
Onboard current sensor
No
Has SD Card Slot
Yes
Internal Memory for Blackbox
8MB
Has PDB
No
Has VTX
No
Has 4 in 1 ESCs
No
Resources
BetaFlight Target
SPRACINGF3EVO
InavFlight Target
SPRACINGF3EVO
