Techninės specifikacijos
Basic Information
Form Factor
30,5 x 30,5 mm
Application
General use
Width
36.0 mm
Height
8.0 mm
Depth
36.0 mm
Weight
7.0 g
Protective case is included
No
Retail Price
US$ 27.00
Release date
Jun 2017
Integrated Circuits
CPU Family
F4
CPU Model
STM32F405
Main MPU
MPU6000
Auxiliar MPU
No
Barometer
BMP280
Compass
No
Inputs and Outputs
PWM Outputs
6
Number of UARTs (total)
3
Inverted UARTs
1
SoftSerial Inputs
1
I2C input
Yes
Buzzer output
Yes
LED Strip Output
Yes
Current Sensor Analog Input
Yes
RSSI Analog Input
Yes
VBAT Input
Yes - Up to 6S (25V)
Shared UART with USB
No
Racing Transponder Led Output
No
Features
Has 5V voltage regulator
Yes - 3A
Soft mounted gyro
No
Soft mounted corners
No
Has OSD
Yes - Native
Onboard current sensor
No
Has SD Card Slot
Yes
Internal Memory for Blackbox
0MB
Has PDB
No
Has VTX
No
Has 4 in 1 ESCs
No
Integrated Radio Receiver
No
Resources
BetaFlight Target
OMNIBUSF4SD
InavFlight Target
OMNIBUSF4V3
