Techninės specifikacijos
Basic Information
Form Factor
30,5 x 30,5 mm
Application
General use
Width
36.0 mm
Height
6.0 mm
Depth
36.0 mm
Weight
5.0 g
Protective case is included
No
Retail Price
US$ 30.00
Release date
Sep 2016
Brand
Airbot
Integrated Circuits
CPU Family
F3
CPU Model
STM32F303
Main MPU
MPU6000
Auxiliar MPU
No
Barometer
BMP280
Compass
No
Inputs and Outputs
PWM Outputs
8
Number of UARTs (total)
3
Inverted UARTs
3
SoftSerial Inputs
2
I2C input
Yes
Buzzer output
Yes
LED Strip Output
Yes
Current Sensor Analog Input
No
RSSI Analog Input
Yes
VBAT Input
Yes - Up to 5S (21V)
Shared UART with USB
No
Racing Transponder Led Output
No
Features
Has 5V voltage regulator
Yes - 1.5A
Soft mounted gyro
No
Soft mounted corners
No
Has OSD
Yes - Native
Onboard current sensor
Yes - Up to 100A
Has SD Card Slot
Yes
Internal Memory for Blackbox
8MB
Has PDB
No
Has VTX
No
Has 4 in 1 ESCs
No
Resources
BetaFlight Target
OMNIBUS
InavFlight Target
OMNIBUS
