Basic Information
Form Factor
30,5 x 30,5 mm
Application
Fixed wing aircraft
Width
36.0 mm
Height
13.0 mm
Depth
56.0 mm
Weight
25.0 g
Protective case is included
Yes
Release date
Dec 2018
Brand
Matek
Integrated Circuits
CPU Family
F7
CPU Model
STM32F765
Main MPU
MPU6000
Auxiliar MPU
No
Barometer
BMP280
Compass
No
Inputs and Outputs
PWM Outputs
12
Number of UARTs (total)
8
Inverted UARTs
8
I2C input
Yes
Buzzer output
Yes
LED Strip Output
Yes
Current Sensor Analog Input
No
RSSI Analog Input
Yes
VBAT Input
Yes - Up to 6S (25V)
Shared UART with USB
No
Racing Transponder Led Output
No
Features
Has 5V voltage regulator
Yes - 3A
Soft mounted gyro
No
Soft mounted corners
Yes
Has OSD
Yes - Native
Onboard current sensor
Yes - Up to 100A
Has SD Card Slot
Yes
Has PDB
Yes - Up to 100A
Has VTX
No
Has 4 in 1 ESCs
No
Integrated Radio Receiver
No
Dedicated VTX UBEC
Yes - 9V or 12V and 2A
Dedicated UBEC for servos
Yes - 5V, 6V or 7.2V and 5A
Resources
InavFlight Target
MATEKF765ULT
Link
Buy from Banggood
Remarks
Also Known as Matek F765-ULT
