Techninės specifikacijos
Basic Information
Form Factor
20 x 20 mm
Application
Fixed wing aircraft
Width
41.0 mm
Height
10.0 mm
Depth
28.0 mm
Weight
7.0 g
Protective case is included
Yes
Retail Price
US$ 35.00
Release date
Jun 2018
Brand
Matek
Integrated Circuits
CPU Family
F4
CPU Model
STM32F411
Main MPU
MPU6000
Auxiliar MPU
No
Barometer
BMP280
Compass
No
Inputs and Outputs
PWM Outputs
7
Number of UARTs (total)
2
Inverted UARTs
1
SoftSerial Inputs
1
I2C input
Yes
Buzzer output
Yes
LED Strip Output
Yes
Current Sensor Analog Input
No
RSSI Analog Input
No
VBAT Input
Yes - Up to 6S (25V)
Shared UART with USB
No
Racing Transponder Led Output
No
Features
Has 5V voltage regulator
Yes - 2A
Soft mounted gyro
No
Soft mounted corners
No
Has OSD
Yes - Native
Onboard current sensor
Yes - Up to 78A
Has SD Card Slot
No
Internal Memory for Blackbox
0MB
Has PDB
Yes - Up to 78A
Has VTX
No
Has 4 in 1 ESCs
No
Integrated Radio Receiver
No
Dedicated VTX UBEC
No
Dedicated UBEC for servos
Yes - 5V or 6V and 3A
Resources
InavFlight Target
MATEKF411
