Techninės specifikacijos
Basic Information
Form Factor
30,5 x 30,5 mm
Application
Fixed wing aircraft
Width
36.0 mm
Height
13.0 mm
Depth
56.0 mm
Weight
25.0 g
Protective case is included
Yes
Retail Price
US$ 50.00
Release date
Apr 2018
Brand
Matek
Integrated Circuits
CPU Family
F4
CPU Model
STM32F405
Main MPU
MPU6000
Auxiliar MPU
No
Barometer
BMP280
Compass
No
Inputs and Outputs
PWM Outputs
9
Number of UARTs (total)
6
Inverted UARTs
1
SoftSerial Inputs
1
I2C input
Yes
Buzzer output
Yes
LED Strip Output
Yes
Current Sensor Analog Input
No
RSSI Analog Input
Yes
VBAT Input
Yes - Up to 6S (25V)
Shared UART with USB
No
Racing Transponder Led Output
No
VTX Power Switch
No
Camera Switch
No
Features
Has 5V voltage regulator
Yes - 3A
Soft mounted gyro
No
Soft mounted corners
Yes
Has OSD
Yes - Native
Onboard current sensor
Yes - Up to 100A
Has SD Card Slot
Yes
Has PDB
Yes - Up to 100A
Has VTX
No
Has 4 in 1 ESCs
No
Integrated Radio Receiver
No
Dedicated VTX UBEC
Yes - 9V or 12V and 2A
Dedicated UBEC for servos
Yes - 5V, 6V or 7.2V and 5A
Resources
InavFlight Target
MATEKF405SE
