Techninės specifikacijos
Basic Information
Form Factor
30,5 x 30,5 mm
Application
Multi-rotor Aircraft
Width
36.0 mm
Height
6.0 mm
Depth
36.0 mm
Weight
6.0 g
Protective case is included
No
Retail Price
US$ 15.00
Release date
Oct 2016
Brand
No Brand
Integrated Circuits
CPU Family
F3
CPU Model
STM32F303
Main MPU
MPU6500
Auxiliar MPU
No
Barometer
No
Compass
No
Inputs and Outputs
PWM Outputs
4
Number of UARTs (total)
3
Inverted UARTs
3
SoftSerial Inputs
0
I2C input
Yes
Buzzer output
Yes
LED Strip Output
Yes
Current Sensor Analog Input
Yes
RSSI Analog Input
Yes
VBAT Input
Yes - Up to 6S (25V)
Shared UART with USB
No
Racing Transponder Led Output
No
Features
Has 5V voltage regulator
Yes - 1A
Soft mounted gyro
No
Soft mounted corners
No
Has OSD
No
Onboard current sensor
No
Has SD Card Slot
No
Internal Memory for Blackbox
0MB
Has PDB
No
Has VTX
No
Has 4 in 1 ESCs
No
Resources
BetaFlight Target
LUX_RACE
InavFlight Target
LUX_RACE
