Techninės specifikacijos
Basic Information
Form Factor
30,5 x 30,5 mm
Application
General use
Width
35.0 mm
Height
7.0 mm
Depth
41.0 mm
Weight
9.0 g
Protective case is included
No
Retail Price
US$ 45.00
Release date
Jul 2018
Brand
Holybro
Integrated Circuits
CPU Family
F7
CPU Model
STM32F745
Main MPU
ICM20689
Auxiliar MPU
No
Barometer
BMP280
Compass
No
Inputs and Outputs
PWM Outputs
6
Number of UARTs (total)
6
Inverted UARTs
6
SoftSerial Inputs
0
I2C input
Yes
Buzzer output
Yes
LED Strip Output
Yes
Current Sensor Analog Input
Yes
RSSI Analog Input
Yes
VBAT Input
Yes - Up to 6S (25V)
Shared UART with USB
No
Racing Transponder Led Output
No
Features
Has 5V voltage regulator
Yes - 2A
Soft mounted gyro
Yes
Soft mounted corners
No
Has OSD
Yes - Native
Onboard current sensor
No
Has SD Card Slot
Yes
Internal Memory for Blackbox
0MB
Has PDB
No
Has VTX
No
Has 4 in 1 ESCs
No
Integrated Radio Receiver
No
Dedicated VTX UBEC
No
Dedicated UBEC for servos
No
Resources
BetaFlight Target
KAKUTEF7
InavFlight Target
KAKUTEF7
Link
Buy from Banggood
Download
Instructions Manual
