Techninės specifikacijos
Basic Information
Form Factor
30,5 x 30,5 mm
Application
Multi-rotor Aircraft
Width
36.0 mm
Height
6.0 mm
Depth
46.0 mm
Weight
10.0 g
Protective case is included
No
Retail Price
US$ 46.00
Release date
Dec 2018
Brand
Matek
Integrated Circuits
CPU Family
F7
CPU Model
STM32F722
Main MPU
ICM20602
Auxiliar MPU
MPU6000
Barometer
BMP280
Compass
No
Inputs and Outputs
PWM Outputs
8
Number of UARTs (total)
5
Inverted UARTs
5
SoftSerial Inputs
1
I2C input
Yes
Buzzer output
Yes
LED Strip Output
Yes
Current Sensor Analog Input
Yes
RSSI Analog Input
Yes
VBAT Input
Yes - Up to 8S (37V)
Shared UART with USB
No
Racing Transponder Led Output
No
VTX Power Switch
Yes
Camera Switch
Yes
Features
Has 5V voltage regulator
Yes - 2A
Soft mounted gyro
No
Soft mounted corners
Yes
Has OSD
Yes - Native
Onboard current sensor
Yes - Up to 184A
Has SD Card Slot
Yes
Has PDB
Yes - Up to 184A
Has VTX
No
Has 4 in 1 ESCs
No
Integrated Radio Receiver
No
Dedicated VTX UBEC
No
Dedicated UBEC for servos
No
Resources
BetaFlight Target
MATEKF722SE
InavFlight Target
MATEKF722SE
