Techninės specifikacijos

Basic Information

Form Factor
20 x 20 mm
Application
Multi-rotor Aircraft
Width
28.0 mm
Height
6.0 mm
Depth
28.0 mm
Weight
4.5 g
Retail Price
US$ 25.00
Release date
Jan 2018
Brand
Matek

Integrated Circuits

CPU Family
F4
CPU Model
STM32F411
Main MPU
MPU6000
Auxiliar MPU
No
Barometer
No
Compass
No

Inputs and Outputs

PWM Outputs
6
Number of UARTs (total)
2
Inverted UARTs
1
SoftSerial Inputs
1
I2C input
Yes
Buzzer output
Yes
LED Strip Output
Yes
Current Sensor Analog Input
Yes
RSSI Analog Input
Yes
VBAT Input
Yes - Up to 6S (25V)
Shared UART with USB
No
Racing Transponder Led Output
No

Features

Has 5V voltage regulator
Yes - 2A
Soft mounted gyro
No
Soft mounted corners
Yes
Has OSD
Yes - Native
Onboard current sensor
No
Has SD Card Slot
No
Internal Memory for Blackbox
0MB
Has PDB
No
Has VTX
No
Has 4 in 1 ESCs
No

Resources

BetaFlight Target
MATEKF411
