Techninės specifikacijos
Basic Information
Form Factor
30,5 x 30,5 mm
Application
Multi-rotor Aircraft
Width
38.0 mm
Height
6.0 mm
Depth
38.0 mm
Weight
11.0 g
Protective case is included
No
Retail Price
US$ 39.00
Release date
Mar 2018
Brand
DYS
Integrated Circuits
CPU Family
F4
CPU Model
STM32F405
Main MPU
MPU6000
Auxiliar MPU
No
Barometer
No
Compass
No
Inputs and Outputs
PWM Outputs
6
Number of UARTs (total)
3
Inverted UARTs
1
SoftSerial Inputs
0
I2C input
Yes
Buzzer output
Yes
LED Strip Output
Yes
Current Sensor Analog Input
No
RSSI Analog Input
Yes
VBAT Input
Yes - Up to 6S (25V)
Shared UART with USB
No
Racing Transponder Led Output
No
Features
Has 5V voltage regulator
Yes - 3A
Soft mounted gyro
No
Soft mounted corners
Yes
Has OSD
Yes - Native
Onboard current sensor
Yes - Up to 120A
Has SD Card Slot
No
Has PDB
Yes - Up to 120A
Has VTX
No
Has 4 in 1 ESCs
No
Resources
BetaFlight Target
OMNIBUSF4
InavFlight Target
OMNIBUSF4
Link
Buy from Banggood
Remarks
With 8pin socket to compatible with 4 in 1 ESC
