Techninės specifikacijos
Basic Information
Form Factor
30,5 x 30,5 mm
Application
Multi-rotor Aircraft
Width
36.0 mm
Height
11.0 mm
Depth
36.0 mm
Weight
14.0 g
Protective case is included
No
Retail Price
US$ 60.00
Release date
Feb 2018
Brand
FPVModel
Integrated Circuits
CPU Family
F7
CPU Model
STM32F745
Main MPU
ICM20608
Auxiliar MPU
MPU6000
Barometer
No
Compass
No
Inputs and Outputs
PWM Outputs
4
Number of UARTs (total)
4
Inverted UARTs
4
SoftSerial Inputs
0
I2C input
Yes
Buzzer output
Yes
LED Strip Output
Yes
Current Sensor Analog Input
No
RSSI Analog Input
Yes
VBAT Input
Yes - Up to 6S (25V)
Shared UART with USB
No
Racing Transponder Led Output
No
Features
Has 5V voltage regulator
Yes - 1.5A
Soft mounted gyro
Yes
Soft mounted corners
Yes
Has OSD
Yes - Native
Onboard current sensor
Yes - Up to 160A
Has SD Card Slot
No
Internal Memory for Blackbox
16MB
Has PDB
Yes - Up to 160A
Has VTX
No
Has 4 in 1 ESCs
No
Integrated Radio Receiver
No
Resources
BetaFlight Target
BETAFLIGHTF7
